Basic Product Description
Patterned conveyor belt is an inclined conveyor belt composed of cover glue with pattern on working face and cover glue with belt core with plane on non-working face. Patterns can be opened or closed, and each pattern can be divided into three types: high, medium and low. It is suitable for powder, granular and small pieces of material conveying with an inclination of less than 40 degrees. It can also convey bagged materials.
C5-C12 Chevron Belt
No.19 V6
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
6 |
1240 |
25 |
≦1219 |
No.20 V6
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
6 |
2309 |
25 |
1200-2300 |
No.8 C5
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
5 |
1400 |
100 |
≦1200 |
No.11 C12.7
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
12.7 |
914.4 |
200 |
≦1300 |
No.18
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
3 |
610 |
43.7 |
650-1200 |
No.17
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
2 |
520 |
24.6 |
600-1200 |
C15 Chevron Belt
No.2 Open V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
580 |
250 |
600-1200 |
No.3 Open V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
520 |
200 |
600-1200 |
No.6 Open V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
300 |
146 |
400-1200 |
No.12 Open V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
385 |
256 |
400-1200 |
No.9 Closed V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
800 |
300 |
850-1200 |
No.16 Closed V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
450 |
250 |
500-1200 |
No.14 Closed V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
600 |
250 |
650-1200 |
No.15 Closed V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
550 |
250 |
600-1200 |
No.13 Closed V C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
750 |
250 |
800-1200 |
No.7 Open U C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
435 |
320 |
500-1200 |
No.22 Open U C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
450 |
160.9 |
500-1200 |
No.5 C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
730 |
300 |
800-1200 |
No.28 Open U C15
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
15 |
540 |
181.9 |
600-1200 |
No.31 Open U C32
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
32 |
900 |
330 |
1000-1200 |
No.33 Open U C20
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
20 |
510 |
250 |
600-1200 |
C25 Chevron Belt
No.23 Open U C25
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
25 |
750 |
450 |
800-1200 |
No.24 Open U C25
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
25 |
450 |
330 |
500-1200 |
No.25 Open U C25
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
25 |
550 |
330 |
600-1200 |
No.26 Open U C25
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
25 |
750 |
330 |
800-1200 |
No.39 Closed V C12.5
|
C.H.(mm) |
C.W(mm) |
C.P(mm) |
B.W(mm) |
|
12.5 |
1067 |
381 |
1200-2200 |
